| 原産地: | 中国(本土) | 銘柄: | WPX | モデル番号: | WPX-AFA-40N | Material: | Aluminum | Characteristic impedence: | 50ohm | Feed voltage: | 24V | Maximum discharge current (Imax): | 20KA | Voltage protection level: | <=600V | Insertion loss: | <=0.2db | Protection Degree: | IP65 | Install method: | Series connection | Response Time: | <=15ns | Connector type: | UHF,N,BNC,DIN |
包装
| 包装: | 標準輸出梱包またはパック要求したように、 |
仕様
Beautiful design 60V 50ohm N connector / Port surge protector
Product DescriptionWhat are the details of our Antenna Surge Protector?
1. SPD operating frequency is 0-4000MHz.
2. Para-feed voltage DC is 24V.
3. Large rated discharge current.
4. Fast response time.
5. Small standing wave, low insertion loss function.
6. Small size, light weight, easy installation and simple maintenance.
Product details
What are the specifications of Antenna surge protector?
Item | WPX-AFA-40N |
Working frequency | DC-4.0Ghz |
Feed Voltage | 24VDC |
Maximum discharge current (Imax) (8/20us) | 20kA |
Characteristic Impedence | 50ohm |
Applicable power | 50W |
Voltage protection level Up | ≤600V |
Insertion loss | ≤0.2db |
Connector type | N |
Working Temperature & Humidity | -40°C~85°C,≤95%(25°C) |
VSWR | 1.2 |
Enclosure material | nickel-plated brass |
Protection degree | IP65 |
Notice:
We'd like to send you best offer according to your accurate requirements on the spec listed as above.
Please feel free to inform us if you have any special requirements on the spec.
We'll make best offer to you at earliest.
What are the applications of our Antenna surge protector?
Applied to the lightning protection of 50Ω coaxial antenna and radio system equipment, overvoltage protection, such as satellite transmission, the receiving system, cable TV transmission system, electronic monitoring systems and so on.It is use for lightning protection zone in LPZ1- LPZ2 area.
Protect all kinds of radio-frequency signal;
Protect network signal;
Protect industrial control signal;
Protect SATV receiving equipment;
Protect supervisory signal;
Package & Shipping , trade terms
Package
Shipping
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door,
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving,
3. Customers specifying freight forwarders or negotiable shipping methods!
4. Delivery Time: 3-7 days for samples; 5-30 days for batch goods.
Payment Terms
1. Payment: T/T, Western unio, MoneyGram,PayPal; 50% for deposit; 50% balance before delivery.
2. MOQ: 1pcs,
3. Warranty: 3 years,
4. Package information: 20pcs per box /The volume of the box is 36cmx24cmx16cm.
Why choose us?
1. We are Alibaba Assessed Gold Supplier;
2. We are a factory manufacturing lightning and surge protectors, best production capability, best
quality control,best Service ;
3. Products inspected by Beijing Testing Center of Surge Protective Devices.
4. 100% QC inspection Before Shipment;
5. Reasonable price with superior quality.
To see our video online, pls click here.
Company InformationCompany View
Company profile
Our certifications
We are factory
We have import and export right
Other certificates
Welcome to download our assessment report by:
http://hnwpx.en.alibaba.com/company_profile/trustpass_profile/report_download.html
FAQFAQ
Q1: How about your experience?
A1: We have our own professional factory and R&D department & more than 5 years producing experience.
Q2: What’s your advantage?
A2: We can make by ourselves from the inside to outside .It greatly increase efficiency and save the cost.
Q3: What’s the standard of package?
A3: Inner box and out carton are made as per international standard and we can make special design according to customer’s need. And if necessary,goods will be packed by pallet to avoid any damage.
Q4: Could you do OEM for us?
A4: Sure,we accept OEM order,please supply with the brand letter of Authorization.
Q5: How about warranty?
A5: Our products give 3 years warranty, 2 years replacement.
Q6: How long should I wait to get the surge protector after payment?
A6: Usually we will send out the products no more than 7 days by courier.
Q7: How many pieces can you produce every month?
A7: We can produce 10000pcs surge protectors every month.
