| 原産地: | 中国(本土) | 銘柄: | DOSIN | モデル番号: | dosin-pl 259 | material: | brass | cable: | lmr 195 | pl259: | UHF connector | Usage: | Multifunctional |
包装
| 包装: | ブリスター包装で100個と101ケースブリスターで包装材pl259uhfrfケーブルコネクタ50Ω工場 |
仕様
Hot sell PL259 connetors for electronic:
The development of type N connector by the Unite States Army/Navy ran directly parallel to the escalation of U.S. involvement in WWII.It was finally released in 1942.shortly after the U.S. officially entered the war,and since that time it has been a staple in RF and microwave applications all over the world.Due to N type connectors joins by one whorl,it has the characteristic of reliable and strong anti-vibration nature.Machinery and electric performance finaly.it is used in vibratioin and environment aborninable radio equipment of terms and instrument and ground launch system join the coaxial cable of the radio frequency extensively.
PL259 Connector Applications:
| Antennas | base stations | Broadcast |
| Cable assemblies | Cellular | Components |
| Instrumentation | Microwave Radio | Mil-Aero |
| PCS | Radar | Radios |
| Satcom | Surge Protection | WLAN |
PL259 Connector Features and Benefits:
| Accommodates a wide range of medium to miniature-sized RG coaxial cables in a rugged medium-sized design |
| Broad line of Military (M39012), Industrial (UG) and Commercial (RFX) grade products available, giving customers choices in weighing cost versus performance benefits |
| Meets many customer application demands with plug styles available in straight and right angle and jack styles available in panel mount, bulkhead mount, and receptacle |
PL259 Connector 50 Ω Specifications:
| Electrical | |
| Impedance | 50 Ω |
| Frequency Range | 0 - 11 GHz |
| Voltage Rating | 1,500 volts peak |
| VSWR | MIL-C-39012 straight connectors: 1.3 max 0-11 GHz MIL-C-39012 right angle connectors: 1.35 max 0-11 GHz |
| Dielectric Withstanding Voltage | 2,500 volts rms |
| Insulation Resistance | 5,000 MΩ minimum |
| Center Contact Resistance | 1.0 mΩ |
| Outer Contact Resistance | 0.2 mΩ |
| RF Leakage | -90 dB minimum at 3 GHz |
| Insertion Loss | .15 dB maximum at 10 GHz |
| Mechanical | |
| Mating | 5/8-24 threaded coupling |
| Braid or Jacket Cable Affixment | All crimps: hex braid crimp Clamps: screw-thread nut and braid clamp |
| Center Conductor Cable Affixment | Crimp: crimp or solder All others: solder only |
| Captivated Contact | All crimps unless specified otherwise |
| Cable Retention | Crimps: 60-120 lbs Clamps: 30-70 lbs |
| Material | |
| Male Contacts | Brass, silver or gold plated |
| Female Contacts | Phosphorous bronze or beryllium copper, silver or gold plated |
| Other metal Parts | Brass with ASTROplate® finish; M39012 has silver finish |
| Insulators | TFE, copolymer of styrene or glass-TFE (hermetic seal) |
| Weatherproof Gaskets | Silicone rubber of synthetic rubber |
| Crimp Ferrule | Copper |
| Environmental | |
| Temperature Range | TFE: -65°C to +165°C |
| Weatherproof | All series N with gaskets are weatherproof |
| Hermetic Seals | Pass helium leak test of 2x10-8 cc/sec |
| Pressurized Shock | Compression seal MIL-STD-202, method 213 |
| Vibration | MIL-STD-202, method 204, test condition B |
| Moisture Resistance | MIL-STD-202, method 106 |
| Corrosion | MIL-STD-202, method 101, test condition B |
| Temperature Cycling | MIL-STD-202, method 102, test condition C |
| Altitude | MIL-STD-202, method 105, test condition C |
| Military | |
| MIL-C-39012 MIL-A-55339 | wher applicable |
